Mase Mariner 700S Generator
MAS002821
€20,207.00
Tax included
Description
Description
The Mase MARINER 700 S is a marine diesel generating set delivering 7,4 kW of continuous AC power at 50 Hz / 115/230 V (single-phase). It is designed for permanent installation on board, covering the vessel’s electrical demand away from shore power: air conditioning, galley, refrigeration, battery chargers, navigation equipment and 230 V outlets.
Engine and cooling
It is powered by a YANMAR 3TNV80F engine of 1267 cm³ and 3 cylinders, with indirect injection and a working speed of 1500 rpm. Cooling is handled by W/W, the usual arrangement in marine installations thanks to its compactness and low vibration.
Installation on board
With dimensions of 868 × 540 × 618 mm and a weight of 230 kg, plan ahead for the installation space, the exhaust and seawater intake runs, and access for routine servicing (filters, raw-water pump impeller and anodes).
Technical specifications
| Specification | Value |
|---|---|
| Brand | Mase |
| Model | MARINER 700 S |
| Engine | YANMAR 3TNV80F |
| Continuous AC power | 7,4 kW |
| Max. engine power | 12,7 CV |
| Frequency | 50 Hz |
| Voltage | 115/230 V |
| Phases | Single-phase |
| Engine speed | 1500 rpm |
| Displacement / cylinders | 1267 cm³ / 3 |
| Injection | Indirect |
| Cooling | W/W |
| Speed regulator | Mechanical |
| Sound level | 51 dB(A) @ 7 m |
| Fuel consumption | 2,3 L/h |
| Dimensions (A × B × C) | 868 × 540 × 618 mm |
| Weight | 230 kg |
| Reference | MAS002821 |
Reference MAS002821. Contact us for availability, lead time and genuine spare parts for this unit.
