Mase Mariner 610S Generator
MAS003027
€16,879.50
Tax included
Description
Description
The Mase MARINER 610 S is a marine diesel generating set delivering 6,1 kW of continuous AC power at 50 Hz / 115/230 V (single-phase). It is designed for permanent installation on board, covering the vessel’s electrical demand away from shore power: air conditioning, galley, refrigeration, battery chargers, navigation equipment and 230 V outlets.
Engine and cooling
It is powered by a KUBOTA Z482 engine of 479 cm³ and 2 cylinders, with injection and a working speed of 3000 rpm. Cooling is handled by W/W, the usual arrangement in marine installations thanks to its compactness and low vibration.
Installation on board
With dimensions of 655 × 473 × 551 mm and a weight of 155 kg, plan ahead for the installation space, the exhaust and seawater intake runs, and access for routine servicing (filters, raw-water pump impeller and anodes).
Technical specifications
| Specification | Value |
|---|---|
| Brand | Mase |
| Model | MARINER 610 S |
| Engine | KUBOTA Z482 |
| Continuous AC power | 6,1 kW |
| Max. engine power | 11,1 CV |
| Frequency | 50 Hz |
| Voltage | 115/230 V |
| Phases | Single-phase |
| Engine speed | 3000 rpm |
| Displacement / cylinders | 479 cm³ / 2 |
| Cooling | W/W |
| Speed regulator | Mechanical |
| Sound level | 55 dB(A) @ 7 m |
| Fuel consumption | 2,6 L/h |
| Dimensions (A × B × C) | 655 × 473 × 551 mm |
| Weight | 155 kg |
| Reference | MAS003027 |
Reference MAS003027. Contact us for availability, lead time and genuine spare parts for this unit.
